Web sensor T6540 - remote CO2 concentration thermometer hygrometer with Ethernet interface

code: T6540

CO2 concentration, temperature and relative humidity t-line Web sensor. Remote alarm.

Web Sensor with built-in CO₂ concentration, relative humidity and temperature sensors.

The CO₂ measurement is based on a 2-source, 2-beam process. CO₂ measurement with long-term stability is guaranteed thanks to the proven non-dispersive infrared (NDIR) CO₂ measurement cell. The unique patented auto-calibration procedure compensates for aging of the infrared source and guarantees high reliability, long term stability and eliminates the need of periodical recalibration in the field.

High precision capacitive polymer sensor ensures excellent long term calibration stability and ultimate accuracy. Measured values are also converted to other humidity interpretation: dew point temperature, absolute humidity, specific humidity, mixing ratio and specific enthalpy.

Carbon dioxide sensor

Included in delivery:

T6540 Web Sensor
Quick start manual
Traceable calibration certificate
Technical support at discussion forum

Features Technical Data Download Optional accessories We recommend

Features

APPLICATIONS:

Building HVAC management
The CO₂ - carbon dioxide level is recently regarded as an important parameter that substantially determines the quality of the interior climate. Especially in buildings where many people gather, such meeting rooms, hospitals, schools, cinemas, theatres and care centres. With the help of CO₂ sensor engineers, technical advisors, environmental experts and health specialists can optimize the ventilation for creation of a healthy interior climate.
CO₂/temperature/humidity monitoring of buildings, history data to DBS Sensor monitor software, alert by email or SMS

Warehouses
CO₂/temperature/humidity monitoring of storage, history data to DBS Sensor monitor software or 3rd party SCADA system

Factories and manufacturing
CO₂/temperature/humidity monitoring for food processing industry, pharmaceutical industry, aerospace industry, etc.

SOFTWARE:

DBS Sensor monitor
Complex solution for data acquisition and analysing. Easy to use and high flexible database software for Comet Transmitters and Regulators.

T-Sensor software
Free configuration utility for Comet Transmitters and Regulators.

SensorReader software
Basic data acquisition utility for Comet Transmitters and Regulators. Software is free for download.

3rd party software
TIRS.NET, Cacti, InTouch, ControlWeb, EasyView, LabVIEW. Support for this software is provided by the 3rd party companies.

FEATURES:

CO₂concentration
	The CO₂ measurement is based on a 2-source, 2-beam process. CO₂measurement long-term stability is guaranteed by non-dispersive infrared (NDIR) CO₂ cell.

Temperature and humidity
	Web Sensor is designed to measuring from internal temperature and humidity sensor. High precision capacitive polymer sensor ensures excellent calibration long term stability, inertia against water and condensation. Web Sensor is designed for use in non-aggressive environment. Degrees Celsius and Fahrenheit are user selectable.

Dew point and computed quantities
	Measured values are also converted to other humidity interpretation: dew point temperature, absolute humidity, specific humidity, mixing ratio and specific enthalpy. User can select one of these interpretation.

Dual line LCD
	Large dual line LCD for simultaneous display of temperature, relative humidity, CO₂ concentration or other calculated humidity interpretation is an advantage. Displayed values are user selectable. Display can be switched off.

Ethernet interface
	10Base-T/100Base-TX Ethernet interface via standard RJ45 connector. IP address can be obtain automatically from DHCP server or set manually. Internet protocol version 4 is supported only.

WWW server
	Actual measured values are accessible via powerful embedded web server. Web pages are ready for access from mobile devices like smartphones and tablets. Device configuration via web pages is possible too. The device allows you to user customize the design of web pages.

History values memory
	Measured values are stored into history memory according selected time interval. Capacity of the memory is 1000 records for each channel. Values inside history memory are not backuped. Memory is cleared after device restart.

History graphs
	Graphs with history values are accessible via web pages. Modern HTML5 canvas graphic component allows to use graphs from thousands of devices. It is not problem show graphs on tablets or smartphones. All modern web browsers are supported - Firefox, Opera, Chrome or Internet Explorer 9.

Email
	Warning email are sent when measured value exceed selected limits. Emails are also send when values returns back into safe range. SMTP authentication is supported, but SSL not. Domain name for SMTP server address is supported. Emails with CSV file attachment can be sent at selected intervals.

History export to CSV

History values can be exported for next processing by the CSV file. CSV file can be processed inside spreadsheet application like Microsoft Excel or OpenOffice Calc. Two formats of CSV file are supported - dot and comma decimal point separators. Timestamps inside CSV file are shown when device time is synchronised by the SNTP server. CSV file can be downloaded from web pages or periodically send as email attachment.

ModbusTCP protocol
	Modbus protocol for communication with SCADA systems or third party software. Device use Modbus TCP protocol version. Two Modbus clients can be connected to device at one moment.

Actual values via XML
	XML protocol for actual measured values reading. This protocol is suitable for device integration into 3rd party SCADA systems.

SNMP protocol
	SNMP version 1 protocol for IT infrastructure. Using SNMP protocol you can read actual measured values, alarm status and alarm parameters. Via SNMP protocol is also possible to get last 1000 measured values from history table. MIB tables with OID description are available.

SNMP Trap
	SNMP Trap for IT infrastructure. The device allows sending Traps to selected Trap receiver server. Traps are sent in case of alarm on channel or at error states like unable to send email, unable to deliver SOAP message, etc.

SOAP protocol
	The device allows to send currently measured values via SOAP v1.1 protocol. The device sends values in XML format to the web server. The advantage of this protocol is that communication is initialized by the device side. Due to it is not necessary use port forwarding.

Syslog protocol
	Syslog protocol for IT infrastructure monitoring systems. The device allows sending text message to selected Syslog server. Messages are sent in case of alarm on channel or at error states like unable to send email, unable to deliver SOAP message, etc.

SNTP protocol - time synchronization
	Time synchronisation with SNTP server. Actual time is shown at web pages and is necessary for timestamps inside CSV files. Synchronisation interval can be set to one day or to one hour.

Technical Data

Technical parameters	Value
Output	Ethernet
Measured Value	CO2 + Relative humidity + Temperature
Construction Type	Ambient Air
Design	Industrial
Temperature Measuring Range	-30 to +60°C
Relay Output	No
Two-State Input	No
Lcd Display	Yes
Range of CO₂ concentration measurement	0 to 2000 ppm
Accuracy of CO₂ concentration measurement	±(50ppm +2% from reading) at 25°C and 1013hPa
Optional range of CO₂ concentration measurement	0 to 10000 ppm ±(100ppm +5% from reading) at 25°C and 1013hPa
Relative humidity range	0 to 100%
Accuracy of relative humidity measurement	±2.5% relative humidity from 5 to 95% at 23°C
Accuracy of temperature output	±0.6°C
Resolution	0.1°C, 0.1%RH, 1ppm
Measuring interval of temperature and relative humidity	2s
Measuring interval of CO₂	15s
Computed values	dew point, absolute humidity, specific humidity, mixing ratio, specific enthalpy
Available temperature units	degrees Celsius, degrees Fahrenheit
Accuracy and range of dew point temperature output - for more details see graphs in manual	±1.5°C at ambient temperature T<25°C and RH>30% range -60 to +80 °C
Temperature compensation of the humidity sensor	all temperature range
Temperature operating range	-30 to +60°C
IP protection	IP30
LAN connection	RJ-45 connector, 10Base-T or 100Base-TX
Communication protocols	WWW, ModbusTCP, SNMPv1, SOAP, XML
Alarm protocols	E-mail, SNMP Trap, Syslog
Configuration	T-Sensor, WWW configuration
Power	9 to 30Vdc, maximum consumption 1W
Power connector	co-axial, diameter 5.5 x 2.1mm
Dimensions	88.5 x 147.5 x 39.5mm (W x H x D), stem length 75mm
Weight	approximately 170g
Warranty	2 years

	size
Instruction Manual	1.4 MB
Quick Start Manual	1.8 MB
Datasheet	1.9 MB
Declaration of Conformity	40 kB
MIB tables	250 kB

Program TSensor - free configuration program for transmitters and transducers, Code: TSensor	more »
TSensor - free configuration program version 3.0.5.0	2.6 MB
TSensor - revision history	8 kB

Program SensorReader - free program for data read and store from one sensor, Code: SensorRead	more »
SensorReader - free program for data recording from one sensor, version 2.0.1.0	1.3 MB

DBS Sensor Monitor - database program for data acquisition from Ethernet sensors P8xxx, Tx5xx, Hx5xx, Code: DBS	more »
DBS Database Sensor Monitor version 2.3.0.1_II	55.2 MB

DBV Database Viewer for database programs DBL, DBM, DBS, Code: DBV	more »
DBV Database Viewer 2.3.0.1	22.8 MB

Firmware for Tx5xx family, Code: S_Tx5xx_FW	more »
Firmware version 1-5-5-00 for Tx5xx	750 kB
Firmware changelog	8 kB
